Back to Basics
Derek Smith • 10 July 2020
Kaya
Photo By: Derek Smith
Hypericum
Photo By: Derek Smith
Back to Basics
Recently someone I know bought a new camera, and of course they had many questions, I had to research these to find the right answers, and the first question was:
What is Lens Focal Length?
Focal length, usually represented in millimeters (mm), is the basic description of a photographic lens. It is not a measurement of the actual length of a lens, but a calculation of an optical distance from the point where light rays converge to form a sharp image of an object to the digital sensor or 35mm film at the focal plane in the camera. The focal length of a lens is determined when the lens is focused at infinity.
Lens focal length also tells us the angle of view—how much of the scene will be captured—and the magnification—how large individual elements will be. The longer the focal length, the narrower the angle of view and the higher the magnification. The shorter the focal length, the wider the angle of view and the lower the magnification.
As an example use a short focal length 24mm (16mm* or 12mm**) to capture the interior of a room, or a landscape view.
* = APS-C crop sensor camera ** = Micro Four Thirds crop sensor camera
What is Aperture in Photography?
Aperture refers to the opening of a lens's diaphragm through which light passes. It is calibrated in f/stops and is generally written as numbers such as 1.4, 2, 2.8, 4, 5.6, 8, 11 and 16. Lower f/stops give more exposure because they represent the larger apertures, while the higher f/stops give less exposure because they represent smaller apertures. This may seem a little contradictory at first but will become clearer as you take pictures at varying f/stops. Be sure to check your manual first to learn how to set Aperture Priority for your camera, then try experimenting to get comfortable with changing the aperture and recognising the effects different apertures will have on the end-result image.
Selecting a wide aperture of f/2 would ensure that only a small portion of the image would be sharp, whereas a narrower aperture of f/10 would ensure that a greater part of the image would be in focus.
What is ISO in Photography?
In digital cameras ISO measures the sensitivity of the image sensor, the lower the number the less sensitive your camera is to light and the lower the noise in the image.
Higher ISO numbers mean your sensor becomes more sensitive to light which allows you to use your camera in low light situations, the trade-off of doing so is more noise in the final image.
An example of a situation you might want to choose a higher ISO would be photographing an indoor sporting event where the light is low and your subject is moving fast. By choosing a higher ISO you can use a faster shutter speed to freeze the movement.
What is exposure in photography?
The light meter in a digital camera calculates the correct exposure of the image based on 3 parameters: ISO, shutter speed, and aperture. This is known as the "exposure triangle". Creatively the photographer chooses 1 or 2 of these parameters based upon the subject. As an example when photographing a moving subject you may select a shutter speed of 1/500 to "freeze" the action, ensuring the the subject is sharp. In the case of a portrait in the front of a distracting background the photographer might select an aperture of f/2 to isolate the subject from the background. The choice of ISO again is an artistic choice, the photographer may choose to set the ISO to "Auto" if the light is variable, alternatively in the case of the portrait set the ISO to the base level of 100 or 200, to give a noise free image.
In the case of the portrait of Kaya, I used a lens with focal length of 90mm (60*, 45**) our location was in shadow under a railway bridge, I set the aperture to f/1.8, and set the ISO to 400. I was using "Aperture Priority" as the camera mode, with the ISO, and aperture fixed the camera calculated the correct shutter speed of 1/200 to give the correct exposure.
The photo of the Hypericum flower was captured with a 120mm macro lens (80*, 60**) ISO 800, aperture f/4, and a shutter speed of 1/60 calculated by the camera.
For further reading on the exposure triangle I found this website to be useful:
https://photographylife.com/what-is-exposure-triangle
